TÜV SÜD ISO 13485:2016 Certified
CE MDR 2017/745 (Class IIa Medical)
Built-in Defibrillator Protection (1kΩ / 10kΩ)
High-Precision Signal Transmission • OEM / ODM Since 2008

Medical-Grade ECG & EKGCables & Leadwires

Source manufacturer of 3-lead, 5-lead, and 12-lead patient monitoring cables. Compatible with GE Marquette, Philips, Mindray, Nihon Kohden, and Schiller. Built with low-noise TPU and 5000V high-pot defibrillation protection.

Defib-Proof Resistors (1kΩ / 10kΩ built-in)
Dual Silver Shielding: Noise < 15μV
Snap / Pinch / Banana / Din Terminations
AHA (AAMI) & IEC Color Coding Available
⚡ Avg. Response: < 2.4 Hours📦 Free Testing Sample Available🤝 OEM / Private Labeling Supported
Premium Series

5-Lead ECG Trunk & Leadwire Set

Defibrillator-Proof
WGVRBDual-layer Shield TPU
Shielding Noise< 15μV Peak
Color CodeAHA / IEC
Warranty12 Months
Compatible: GE, Philips, Mindray, Schiller

Trusted OEM Replacement Compatible with Leading Patient Monitor Systems

PHILIPS Logo
PHILIPSTC & IntelliVue Series
GE HealthCare Logo
GE HealthCareMAC 1200/2000 & Solar
MINDRAY Logo
MINDRAYBeneHeart & BeneView
MASIMO Logo
MASIMORainbow Direct Leads
NELLCOR Logo
NELLCORECG Intermediary Cables
NIHON KOHDEN Logo
NIHON KOHDENCardiofax Series
SCHILLER Logo
SCHILLERCardiovit Series
DRÄGER Logo
DRÄGERInfinity MultiMed Pods
5000V High-Pot Tested • Zero BreakdownDefibrillation Proof Resistors (1kΩ / 10kΩ / 20kΩ)Free Clinical Evaluation Samples Available
Diagnostic & Monitoring Cross-Reference

Find Your ECG / EKG Equipment Compatibility

Select your monitor or electrocardiograph brand below to check trunk cable pinouts, leadwire options (Snap/Pinch/Banana), and built-in resistor configurations. Click [Get Quote] to prefill your inquiry instantly.

Brand / ManufacturerECG / EKG Device ModelsConnector & Pin ConfigurationLead Configuration & TerminationDirect Action
Philips MedicalIntelliVue MP20-MP90, MX400-MX800, HeartStart XL, PageWriter TC series12-Pin Round Connector / Built-in 1kΩ Defib Resistors3-Lead / 5-LeadSnap / GrabberAHA & IEC
GE Healthcare / MarquetteDash 2000/3000/4000/5000, Solar 8000, Carescape B650/B850, MAC 1200/200011-Pin Rectangle Connector (Multi-Link) / 10kΩ Protection3/5-Lead Multi-Link10-Lead EKG BananaDual Shield
MindrayBeneView T5/T8, BeneVision N12/N17, iMEC, ePM series, BeneHeart D3/D612-Pin Round Connector / 6-Pin Defibrillator Proof (1kΩ / 10kΩ)3/5-Lead One-PieceDetachable TrunkAAMI / IEC
Nihon KohdenLife Scope BSM-2300, BSM-4100, BSM-5100, cardiofax ECG-1250/1350/235014-Pin Round Connector / DB15 Diagnostic EKG Plug3-Lead / 6-Lead Cable10-Lead EKG HarnessPinch / Clip
Schiller / Welch AllynCardiovit AT-1, AT-2, AT-10 plus, Propaq CS / Encore, PIC 50DB15 Male / Round Multi-pin / Built-in 10kΩ Anti-Defibrillation10-Lead Patient Cable4.0mm Banana / SnapResistor Protected
Dräger MedicalInfinity Delta, Vista 120, MultiMed 5 / 6 Pods, Siemens SirecustMultiMed Pod Connector / 16-Pin Round / 5000V Dielectric PassMultiMed 5-LeadSnap / GrabberLow-Noise TPU
Spacelabs HealthcareUltraview, Command Module, 90369, 91369, Qube, Xhibit series17-Pin Round Connector / TruLink Technology Compatibility3-Lead / 5-Lead TruLinkSnap / Pinch LeadsMolded Strain Relief
💡Can't find your specific monitor connector or OEM part number? We engineer custom mold pinouts in 14 days.
Clinical Grade Quality

Core ECG & EKG Product Lines & Technical Specifications

Full clinical range: 3-lead, 5-lead, 10-lead and 12-lead cable assemblies engineered for low noise, defibrillator shock resistance, and maximum clinical durability.

ECG/EKG Cables
12-Lead Diagnostic & Resting

ECG/EKG Cables

One-piece diagnostic ECG cables for resting electrocardiographs with built-in 10kΩ/20kΩ defibrillation protection resistors.

  • DB15, DB25, and proprietary multi-pin connectors
  • 4.0mm banana, Din 3.0, snap, and grabber terminations
  • Compatible with Schiller, GE MAC, Nihon Kohden, Edan
ECG Trunk Cable & Leadwires
ICU & Bedside Modular Bridge

ECG Trunk Cable & Leadwires

Modular trunk cables and detachable leadwires designed for bedside patient monitoring systems.

  • 12-Pin Round, 11-Pin Multi-Link, MultiMed interfaces
  • 3-lead, 5-lead, and 6-lead configurations (Snap & Grabber)
  • Double-shielded TPU jacket resistant to disinfectant wipes
Disposable ECG Leadwires
Single-Patient Infection Control

Disposable ECG Leadwires

Pre-wired peelable ribbon leadwire sets engineered for OR, emergency, and ICU environments to prevent cross-contamination.

  • Single-patient use eliminates hospital cleaning costs
  • Color-coded ribbon wire with tangle-free peel design
  • Radiotranslucent carbon fiber options for X-ray / Cath lab
Multi-Parameter Patient Cables
Integrated Bedside Hubs

Multi-Parameter Patient Cables

Integrated all-in-one patient cable hubs combining ECG, SpO2, and dual-channel temperature monitoring into a single master trunk.

  • Reduces bedside cable clutter by over 60%
  • Integrated Dräger MultiMed & Philips Quad style hubs
  • High-density molded strain relief withstands 20kg tensile
Holter Recorder ECG
24-48h Ambulatory Cardiology

Holter Recorder ECG

Ultra-flexible shielded leadwire sets for continuous ambulatory cardiac recording with zero baseline drift.

  • Ultra-low microphonic noise copper-tinsel conductors
  • Compatible with DMS 26-Pin, Mortara, Rozinn, Biocare
  • 7-lead, 10-lead, and 12-lead snap lead sets
EKG Accessories
Electrodes & Hardware

EKG Accessories

Comprehensive clinical hardware including limb clamps, suction chest bulbs, alligator adapters, and lead separators.

  • Adult & pediatric suction chest electrodes (Ag/AgCl)
  • 4-color peripheral limb clamp electrode sets
  • 4.0mm banana to snap/clip alligator converter adapters
Uncompromised Medical Governance

Verifiable Medical Certifications & Quality Factory

We manufacture strictly under ISO 13485 QMS standards with complete audit trails, CE MDR certificates, and FDA clearances for smooth customs clearance worldwide.

TÜV SÜD✓ Active Valid

ISO 13485:2016

Q5 074312 0019

Medical Devices Quality Management System covering SpO2 sensors, ECG patient cables and connector assemblies.

CE MDR 0123✓ European Union

CE MDR (EU 2017/745)

HZ 214589-MDR

Class IIa conformity assessment under European Medical Device Regulation for hospital clinical use.

US FDA✓ FDA Cleared

FDA 510(k) Premarket

510(k) Number: K180xxx

Cleared for distribution in the United States healthcare market; compliant with FDA QSR (21 CFR Part 820).

ISO 10993✓ Safety Pass

Biocompatibility Pass

GLP Certified Laboratory

Rigorous cytotoxicity, intracutaneous irritation, and delayed skin sensitization tests passed for all patient-contact TPU parts.

Manufacturing Infrastructure

4,000 sqm Intelligent Factory in Shenzhen

Established in 2008 with 100+ skilled technicians, Class 100,000 cleanrooms, and fully automated wire-stripping and terminal-crimping lines.

100%High-pot, Pinout & Continuity QC
>10,000Cycles Dynamic Flex Testing
Medke Class 100,000 Cleanroom Workshop
Cleanroom
Class 100,000 Cleanroom

ESD-protected dust-free medical sensor assembly

Medke Reliability & Testing Lab
Testing Lab
Flex & Tensile Testing Lab

100% semi-finished inspection & >10k bend test

Medke Finished Goods Warehouse
Warehouse
Finished Goods Buffer

123+ core SKUs in stock ready to ship

⚡ Guaranteed 2.4-Hour Medical Engineering Response

Request Direct Factory Pricing & Specifications

Get tiered wholesale pricing, technical pinout diagrams, and free evaluation samples directly from our engineering sales team.

Primary contact for engineering follow-up.

Official tiered pricing & spec sheets sent here.

Auto-filled when clicking any brand row or product above.

Helps calculate regional delivery time & tax rates.

100% Privacy Protected • NDA AvailableDirect Manufacturer Wholesale • Zero Middleman Markups
Procurement FAQ

Frequently Asked Questions

Key details about MOQ, clinical evaluation samples, OEM tooling, and global export shipping.

All Medke diagnostic ECG and bedside monitoring cables feature integrated high-voltage current-limiting resistors (1kΩ, 10kΩ, or 20kΩ depending on monitor circuit requirements). Every production batch undergoes 5000V high-pot spark testing to guarantee patient isolation and equipment protection during emergency defibrillation shocks.
